Green Energy 200W Monocrystalline Solar Panel

Electrical Characteristics (STC)
Maximum Power (Pmax): 200 Watts
Maximum Power Voltage (Vmp): ~18.5V - 19.5V (Optimized for 12V battery systems)
Maximum Power Current (Imp): ~10.3A - 10.8A
Open Circuit Voltage (Voc): ~22.5V - 23.5V
Module Efficiency: Up to 21.0%
Mechanical Specifications
Cell Type: A-Grade Monocrystalline (Half-cut cell technology)
Dimensions: Approximately 1500 x 700 x 30 mm
Weight: ~11.5 kg - 13 kg
Frame: High-strength anodized aluminum alloy
Glass: 3.2mm low-iron, high-transmission tempered glass
Junction Box: IP67 waterproof rated with bypass diodes
Key Performance Features
High Power Output: One of the most efficient panels for its size, delivering more power in less space.
All-Weather Reliability: Engineered to generate electricity even during cloudy or hazy conditions in Kenya.
Durable Build: Anti-reflective coating and impact-resistant glass protect against hail and high winds.
Easy Installation: Pre-drilled holes on the back of the frame allow for fast mounting on rooftops or ground stands.
What This Panel Can Power
In a typical setup, a single 200W panel can support:
Multiple LED bulbs (6-10 bulbs).
A 32" to 43" DC/AC Solar TV for several hours.
Charging multiple smartphones and a laptop.
Small appliances like a DC fan or a radio.
*Standard Test Conditions (STC): Irradiance 1000W/m², Cell Temperature 25°C, AM1.5.
